Customer Technical Parameters:
| ITEM | UNIT | JM802H |
| Operating Weight | kg | 2000 |
| Compaction width | mm | 1000 |
| Vibration frequency | Hz | 60 |
| Theoretical amplitude of vibration | mm | 0.45 |
| Exciting force | kN | 20 |
| Travel speed | km/h | 0～12 |
| Engine model | Yanmar 3TNV88 | |
| Engine power/speed | kW / r/min | 26.6/3000 |
| Overall dimensions(L*W*H) | mm | 2365*1140*2530 |
Quality assurance: Meeting the strict quality standards of ISO and SGS is the primary condition for ensuring customer satisfaction and trust in our products.
Solution
Customization function: We work closely with the engineering team to customize hydraulic double drum vibratory rollers. The modification includes specialized paint treatment, voltage adjustment, and user-friendly features to ensure optimal performance under local climate and operating conditions.
Main Features
Hydraulic double steel wheels, electronically controlled vibration start, high excitation force, good compaction performance.
Hydraulic steering, articulated frame, flexible operation.
Electric pressure sprinkler system, large capacity anti-corrosion water tank.
Hydraulic brake, electrically controlled self-locking parking brake.
The front cover of the engine can be flipped up at a large angle for easy maintenance.
Equipped with imported Yangma engines and Poclian hydraulic components, the performance is reliable.
